Controller CLARE 5:
Controller CLARE 5

Changing the set temperature





By pressing the button  (Stop) on the home screen while the program is running, we get to the screen for preparing to end the program. If the Settings (article Changing the program on the fly) allow changing the parameters of the program while it is running, we will see in the upper part of the screen the possibility of changing the current set temperature (see upper picture).

The temperature can be changed with the arrows  (Up) a  (Down) in the range of 0.01 - up to the maximum temperature (according to Settings - article Maximum control temperature). The step of changing the set temperature after pressing the arrow can be set in Settings (article Step on temperature change).

The second option to change the set temperature is to press the button directly labeled  Temperature , which will bring us to the set temperature entry screen. Here the control is exactly the same as in the previous article Set temperature. The only change is the display of the inscription  Current temperature  instead of  Manual temperature . Confirm the newly set temperature here with the button  (OK) and the controller will start using it immediately.
