Controller CLARE 5

Change the current ramp





By pressing the button  (Stop) on the home screen while the program is running, we get to the screen for preparing to end the program. If the Settings (article Changing the program on the fly) allow changing the parameters of the program while it is running, we will see in the upper part of the screen the possibility of changing the current ramp (see upper image).

The ramp can be changed with the arrows  (Up) a  (Down) in the range of 0.01 - 6000.00 °C per minute. The ramp change step after pressing the arrow can be set in Settings (article Step when changing the ramp).

The second option to change the ramp is to press the button directly labeled  Ramp , which will bring us to the current ramp entry screen. Here the control is exactly the same as in the previous article Rate of temperature change. The only change is the display of the inscription  Current ramp  instead of  Manual ramp . Confirm the newly entered rate of temperature change here with the button  (OK) and the controller will start using it immediately.
